APR 25/50
APR 25/50
APR 25/50
APR 25/50
APR 25/50
APR 25/50
APR 25/50
APR 25/50

APR 25/50

Vibratory Plates

Diesel
Engine Fuel
298 lb
Operating Weight
35%
GRADEABILITY
Request Price View Product Specifications

Product Overview

Versatile Compaction Solutions for Diverse Applications


“The APR 25 Series offers robust performance with options for varied working widths, making it ideal for multiple applications. Its reversible vibratory plate ensures efficient compaction on diverse surfaces.

– Superior compaction performance

– Ergonomic design for operator comfort

– Simplified maintenance and inspection”


Superior Compaction

Superior Compaction

The powerful vibratory system generates high compaction forces, ensuring fast and comprehensive compaction across varied surfaces, enhancing productivity in earthwork and paving applications.


Ergonomic Design

Ergonomic Design

The low-vibration guide handle, with industry-leading HAV values below 2.5 m/sec², protects the operator, eliminating the need for time-consuming record keeping, and ensuring comfort during extended use.


Hydrostatic Steering Control

Hydrostatic Steering Control

This feature provides simple and accurate control, even in confined spaces, allowing for precise maneuvering and efficient operation in challenging environments.


Easy Maintenance

Easy Maintenance

Daily inspections and maintenance are simplified with toolless access to key components, ensuring that the machine remains in optimal working condition with minimal downtime.


Optional Features

Optional Features

Optional equipment such as transport wheels and a water sprinkler system for asphalt work increase the machine’s versatility, making it adaptable to specific job requirements.


Product Specifications for APR 25/50

Description
Specifications
Downloads
Contact us for More Details

APR 25/50 Key Specifications

Engine Fuel

Diesel

Operating Weight

298 lb

GRADEABILITY

35%

Engine

Hatz 1B20

Engine Fuel

Diesel

ENGINE OUTPUT AT RPM

3.1 kW / 4.2 HP 3000

FUEL CONSUMPTION

0.9 l/h (0.2 gal/h)

Operating Weight

298 lb

MACHINE WEIGHT (WITH OPTIONS)

322 lb

BASE PLATE LENGHT

330 mm (13.0 in)

MACHINE LENGHT

700 mm (27.6 in

WITH HANDLE

1140 mm (44.9 in)

MACHINE HEIGHT

755 mm (29.7 in)

HANDLE HEIGHT (WORK)

1000 mm (39.4 in)

HANDLE HEIGHT (TRANSPORT)

1180 mm (46.5 in)

MACHINE WIDTH

380 mm (15.0 in)

MAX. VIBRATION FREQUENCY

95 Hz (5700 vpm)

MAX. CENTRIFUGAL FORCE

25 kN (5620 lbf)

WORKING SURFA

479 m²/h (5154 ft²/h)

SPEC. SURFACE PRESSURE

19,9 N/cm² (28,9 psi)

AMPLITUDE

1.5 mm (0.1 in)

HAND-ARM VIBRATIONS

< 2.5m/sec²

SPEED

21 m/min (69 ft/

FUEL TANK

3.0 l (0.8 gal)

GRADEABILITY

35%

MAX. INCLINE TO ALL SIDES

30°

WATER TANK

9.4 l (2.5 gal)
