Product Overview
Compact Power for Challenging Terrains
“The D8 and D6 dumper trucks offer unmatched versatility and efficiency in off-highway conditions. Designed for compactness and strength, they excel in demanding environments.
– Dual-view rotating seat for enhanced visibility
– Hydrostatic transmission for smooth operation
– High load capacity for increased productivity”
The rotating dual-view driver’s seat allows operators to have a clear view in both directions, significantly improving safety and operational efficiency in tight and challenging workspaces.
The hydrostatic transmission system ensures seamless power delivery, providing operators with precise control and reducing wear and tear on the engine, ideal for varied terrain.
With a maximum load capacity of up to 8,000 kg, the D8 and D6 models allow for the transportation of larger volumes, reducing the number of trips and increasing overall site productivity.
The compact design of these dumper trucks enables them to maneuver through narrow passages and confined spaces, making them perfect for urban construction sites and rugged terrains.
Equipped with a Yanmar engine, these trucks deliver consistent power and reliability, ensuring they can handle the toughest jobs with ease and efficiency.
Horsepower
72 hpRated Operating Capacity
13 lbGradeability
50 %Max load capacity
13 lbDump body water level capacity
3.200Dump body struck capacity
4.600Dump body heaped capacity
6.100Unloading system
RearDrivers'seat
Rotating - Dual viewFrame
FixedEmpty weight
5.100Transmission
HydrostaticCabin
Rops-FopsHorsepower
72 hpBrand
YanmarModel
4TNV98CT-NYI2DRated Operating Capacity
13 lbMax speed
25 (40 opt.) km/hGradeability
50 %Turning radius
4400 mmTraction
AWSTyres
12.5/80-18 16 PRAxle oscillation lock
OptionalHydraulic system
Duble gear pumpWorking pressure
180 barStarter motor
12/3 V/kWBattery
12/110 V/AhFuel
125Hydraulic
125
