E37 – General Trading & Equipment Co.

E37

32 hp

Horsepower

3

Number of cylinders

8240 Ib

Operating Weight

Request Price View Product Specifications

Product Overview

Unmatched Versatility and Performance

The Bobcat E37 Compact Excavator offers superior performance and versatility for demanding tasks. Its robust design ensures reliability and efficiency in various applications.

– High digging force for tough jobs

– Efficient hydraulic system for smooth operation

– Compact design for easy maneuverability”

Powerful Engine

Powerful Engine

The E37 is equipped with a Kubota diesel engine delivering 24.4 kW of power, ensuring optimal performance and fuel efficiency for all your excavation needs.

Advanced Hydraulic System

Advanced Hydraulic System

Featuring a single outlet variable displacement pump, the hydraulic system provides a total capacity of 101.20 L/min, ensuring smooth and precise operation.

Compact Design

Compact Design

The compact dimensions of the E37 allow for easy navigation and operation in confined areas, making it ideal for urban construction sites.

Enhanced Operator Comfort

Enhanced Operator Comfort

The cab includes ergonomic controls, a high-back seat, and climate control options, ensuring comfort and safety for the operator during long working hours.

Versatile Attachments

Versatile Attachments

With features like adjustable auxiliary hydraulics and a clamp-ready design, the E37 can be equipped with a range of attachments to handle diverse tasks efficiently.

Product Specifications for E37

Description

Specifications

Downloads

Contact us for More Details

E37 Key Specifications

Horsepower

32 hp

Number of cylinders

3

Operating Weight

8240 Ib

Weights

Operating weight with canopy, long arm, steel tracks and bucket (ISO 6016)

3738 kg

Additional weight for cab with heating

118 kg

Additional weight for cab with HVAC

137 kg

Weight reduction with rubber tracks

-96 kg

Weight reduction with standard arm

-12 kg

Ground pressure with rubber tracks

33 kPa

Engine

Make / model

Kubota / D1803-M-D1-E3B-BC-3

Engine Cooling

8

Engine Fuel

Diesel

Horsepower

32 hp

Number of cylinders

3

Displacement

1862 cm 3

Maximum power @ 2200 rpm (ISO 14396)

33 hp

Maximum torque (SAE)

97 Nm

Performance

Digging force, dipperstick (ISO 6015)

20790 N

Digging force, long dipperstick (ISO 6015)

18010 N

Digging force, bucket (ISO 6015)

33430 N

Drawbar pull

34132 N

Travel speed, low range

2 km/h

Travel speed, high range

4 km/h

Hydraulic System

Pump type

Single outlet variable displacement, load sensing torque pump with gear pumps

Total hydraulic capacity

101 L/min

Auxiliary flow

64 L/min

Auxiliary relief

206 bar

Slew System

Boom swing, left

75.0°

Boom swing, right

55.0°

Slew rate

8 RPM

Fluid Capacities

Cooling system

8.00 L

Engine lubrication plus oil filter

5.20 L

Fuel reservoir

52.00 L

Hydraulic reservoir

8.30 L

Hydraulic system

39.70 L

Environmental

Noise level LpA(EU Directive 2006/42/EC)

80 dB(A)

Noise level LWA(EU Directive 2000/14/EC)

94 dB(A)

Whole body vibration (ISO 2631–1)

1.20 ms-2

Hand-arm vibration (ISO 5349–1)

0.85 ms-2

Dimension

Operating Weight

8240 Ib

Bobcat- E37_Leaflet_B451240_12-2019_HighRes
