Product Overview
Unmatched Lifting Performance and Efficiency
The Perkins 1104D-44TA Series offers exceptional lifting capabilities and operational efficiency, ideal for demanding environments.
– Lifting height up to 17,466 mm
– Rated capacity of 4,000 kg
– Hydrostatic transmission for smooth operation
Designed to manage heavy loads with ease, the Perkins 1104D-44TA Series can lift up to 4,000 kg, making it perfect for construction and industrial applications.
The hydrostatic transmission with electronic regulation provides seamless control and adaptability, enhancing the operator’s ability to maneuver in tight spaces with precision.
Equipped with a Perkins 1104D-44TA diesel engine, this machine delivers 100 HP, ensuring reliable performance and fuel efficiency for extended operations.
Safety is prioritized with features such as hydrostatic engine braking and passive parking and emergency brakes, ensuring secure operation in various conditions.
The gear pump with LS valve and a 100 L/min capacity ensures efficient hydraulic performance, supporting quick and responsive lifting and lowering actions.
Horsepower
100.0 HPNumber of cylinders
4Rated Operating Capacity
8818 lbLifting height — on stabilisers
17466.0 mmLifting height — on tyres
16200.0 mmRated capacity
4000 kgCapacity (at max. height on stabilisers)
2500 kgCapacity (at max. height on tyres)
1000 kgCapacity (at max. reach on stabilisers)
560 kgMax. reach on tyres
12800.0 mmWeight (unladen)
10580 kgStandard tyres
DUNLOP 400/80-24 156B T371st gear / low range
8.5 km/h1st gear / high range
30.0 km/hTransmission
Hydrostatic with electronic regulationMain drive
Hydrostatic motorMake / Mode
Perkins / 1104D-44TAEngine Cooling
WaterEngine Fuel
DieselHorsepower
100.0 HPRated power (ISO 14396:2002) at 2200 RPM
100 hpMaximum torque at 1400 RPM
410.0 NmNumber of cylinders
4Displacement
4.40 LPump type
Gear pump with LS valvePump capacity
100.00 L/minRelief valve pressure setting
250.00 barLift time - no load
14.0 sLower time - no load
8.5 sTelescope in time at max. reach - no load
20.5 sTelescope in time at max. height - no load
18.0 sTelescope out time at max. reach - no load
31.5 sTelescope out time at max. height - no load
31.5 sEngine braking
HydrostaticParking and emergency brake
Passive brakeFuel tank
145.00 LHydraulic reservoir
76.00 LLevel of acoustic power (LWA)
106 dB(A)Rated Operating Capacity
8818 lb
