Product Overview
Powerful Performance and Versatility
The Bobcat D34 Telehandler delivers exceptional lifting capabilities and reliable performance for demanding tasks. Ideal for construction and agricultural use, it combines strength and precision.
– Lifting height up to 13,656 mm
– Rated capacity of 4,100 kg
– Hydrostatic transmission for smooth operation
With a maximum lifting height of 13,656 mm and a rated capacity of 4,100 kg, this telehandler is designed for heavy-duty tasks, ensuring efficiency and reliability in various applications.
The hydrostatic transmission with electronic regulation offers precise control and smooth operation, enhancing maneuverability and reducing operator fatigue during extended use.
Equipped with a Bobcat D34 diesel engine, it delivers 75 HP at 2400 RPM, providing the necessary power for demanding tasks while maintaining fuel efficiency.
Features such as hydrostatic engine braking and passive parking brake enhance safety, while low operator noise levels improve comfort during operation.
Standard DUNLOP 400/80-24 tyres provide excellent traction, allowing the telehandler to perform efficiently on different surfaces, whether on stabilisers or tyres.
Horsepower
75.0 HPNumber of cylinders
4Rated Operating Capacity
9038 lbLifting height — on stabilisers
13656.0 mmLifting height — on tyres
13300.0 mmRated capacity
4100 kgCapacity (at max. height on stabilisers)
4100 kgCapacity (at max. height on tyres)
2500 kgCapacity (at max. reach on stabilisers)
1250 kgCapacity (at max. reach on tyres)
350 kgMax. reach on tyres
9449.0 mmWeight (unladen)
9890 kgStandard tyres
DUNLOP 400/80-24 156B T371st gear / low range
4.8 km/h1st gear / high range
24.0 km/hTransmission
Hydrostatic with electronic regulationMain drive
Hydrostatic motorMake / Model
Bobcat D34Engine Cooling
CoolantEngine Fuel
DieselHorsepower
75.0 HPRated power (ISO 14396:2002) at 2400 RPM
75.0 HPRated power (ISO 14396:2002) at 2400 RPM
55.2 kWMaximum torque at 1400 RPM
325.0 NmNumber of cylinders
4Displacement
3.40 LPump type
Gear pump with LS valvePump capacity
80.00 L/minRelief valve pressure setting
250.00 barLift time - no load
16.0 sLower time - no load
10.0 sTelescope in time at max. reach - no load
13.5 sTelescope in time at max. height - no load
12.5 sTelescope out time at max. reach - no load
23.5 sTelescope out time at max. height - no load
23.5 sEngine braking
HydrostaticParking and emergency brake
Passive brakeFuel tank
145.00 LHydraulic reservoir
76.00 LOperator noise level (LpA) (EN 12053)
74 dB(A)Level of acoustic power (LWA)
104 dB(A)Whole body vibration (EN 13059)
1.20 ms-2Rated Operating Capacity
9038 lb
